58D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
Play/Stop/Pause:
Speed:
Cue In/Cue out:
Step Forward/Reverse:
Fast Forward/Reverse:
Select a camera/ video and click this button to play/stop/pause a particular channel.
Click the + or - button to increase or decrease the playback speed.
Click the Cue In or Cue Out button to set the period for Save Video.
Click to pause the playback and move to next frame or last frame.
Click to pause the playback and move to next minute or last minute.
Play/Stop/Pause
Step Forward/Reverse Fast
Forward/Reverse
Cue In/Cue Out
Speed
