26D-Link DNS-722-4/DNS-726-4 User Manual
Section 3 - Configuration
Enter a name for the NVR, or leave the default values
and click Next to continue.
When the wizard completes, click Back to go back
and make changes or click Restart to restart the NVR
and save the conguration.
While the NVR is restarting, a countdown screen will
appear.
