Asus tuf sabertooth z97 mark s [10/176] Sabertooth z97 mark s specifications summary
![Asus tuf sabertooth z97 mark s [10/176] Sabertooth z97 mark s specifications summary](/views2/1161698/page10/bga.png)
x
Storage
Intel
®
Z97 Express Chipset with RAID 0, 1, 5, 10 and Intel
®
Rapid Start Technology 13 support
- 1 x SATA Express port (black at the bottom, compatible with 2
x SATA 6.0 Gb/s ports)
- 4 x SATA 6.0 Gb/s ports with RAID 0, 1, 5, and 10 support
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid
Start Technology, and Intel
®
Smart Connect Technology*
1 x ASMedia
®
SATA 6Gb/s controller**
- 2 x SATA 6.0 Gb/s ports (beige)
* These functions will work depending on the CPU installed.
** These SATA ports are for data hard drives only. ATAPI devices are not
supported.
Audio
Realtek
®
ALC1150 8-channel High denition audio CODEC
- Audio shielding ensures precision analog/digital separation
and greatly reduced multi-lateral interference
- Separate layer for left and right track, ensuring both sound
deliver equal quality
- Top notch audio sensation delivers according to the audio
conguration
- Audio amplier to enhance the highest quality sound for
headphone and speakers
- High Quality 112dB SNR stereo playback output (Line-out at
rear) and 104dB SNR recording input (Line-in) support
- Absolute pitch 192khz/24bit true BD lossless sound
- BD audio layer content protection
- Supports jack-detection, multi-streaming, and front panel jack-
retasking
- Optical S/PDIF out ports at rear I/O
USB
Intel
®
Z97 Express Chipset - supports ASUS USB 3.0 Boost
- 4 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at rear panel (blue)
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at rear
panel)
ASMedia
®
USB 3.0 controller - supports ASUS USB 3.0 Boost
- 2 x USB 3.0/2.0 ports at rear panel
(continued on the next page)
SABERTOOTH Z97 MARK S specifications summary
