Asus tuf sabertooth z97 mark s [68/176] Audio i o connections

2-14

Chapter 2: Basic installation

Chapter 2

2.3.2 Audio I/O connections

Audio I/O ports

Connect to Headphone and Mic

Connect to Stereo Speakers

Connect to 2.1 channel Speakers
