ASUS SABERTOOTH Z97 MARK S
1-17
Chapter 1
DDR3 2133 MHz capability
DDR3 2000 MHz capability
DDR3 1866 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support
(Optional)
1 2 4
Silicon
Power
SP004GXLYU213NSA(XMP) 4GB SS - - 2133-11-12-11-30 - • • •
Silicon
Power
SP008GXLYU213NSA(XMP) 8GB DS - - 2133-11-12-11-30 - • • •
Transcend TX2133KLH-16GK(XMP) 16GB ( 2x 8GB ) DS - - 2133-10-11-10-27 1.6 • • •
Transcend TX2133KLN-8GK(XMP) 8GB ( 2x 4GB ) DS - - 2133-10-11-10-27 1.6 • • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1 2 4
AEXEA AXA3ES4GK2000LG28V(XMP) 4GB ( 2x
2GB )
DS - - - 1.65 • • •
Asint SLA302G08-ML2HB(XMP) 4GB DS Hynix H5TQ2G83BFRH9C 9-9-9-27 - • • •
GEIL GUP34GB2000C9DC(XMP) 4GB ( 2x
2GB )
DS - - 9-9-9-28 1.65 • • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support
(Optional)
1 2 4
CORSAIR CMD16GX3M2A1866C9 (Ver5.29)
(XMP)
16GB ( 2x 8GB ) DS - - 1866 9-9-
9-27
1.5 • •
CORSAIR CMD16GX3M4A1866C9 (Ver4.13)
(XMP)
16GB ( 4x 4GB ) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMD16GX3M4A1866C9 (Ver8.16)
(XMP)
16GB ( 4x 4GB ) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMD32GX3M4A1866C9 (Ver3.24)
(XMP)
32GB ( 4x 8GB ) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMD8GX3M2A1866C9 (Ver4.13)
(XMP)
8GB ( 2x 4GB ) DS - - - 1.5 • • •
CORSAIR CMD8GX3M2A1866C9 (Ver5.12)
(XMP)
8GB ( 2x 4GB ) DS - - 9-10-9-27 1.5 • •
CORSAIR CMD8GX3M2A1866C9 (Ver8.16)
(XMP)
8GB ( 2x 4GB ) DS - - 9-10-9-27 1.5 • •
CORSAIR CMT32GX3M4X1866C9(Ver3.23)
(XMP)
32GB ( 4x 8GB ) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMY16GX3M2A1866C9 (Ver 4.21)
(XMP)
16GB ( 2x 8GB ) DS - - 9-10-9-27 1.5 • • •
CORSAIR CMY8GX3M2A1866C9 (Ver3.24)
(XMP)
8GB ( 2x 4GB ) DS - - 9-10-9-27 1.5 • • •
(continued on the next page)
