ASUS SABERTOOTH Z97 MARK S
1-21
Chapter 1
DDR3 1600 MHz capability
(continued on the next page)
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1 2 4
KINGSTON KHX16009CD3K2/8GX(XMP) 8GB (2x4GB) DS - - 9-9-9-
27
1.65 • • •
KINGSTON KHX1600C9D3B1/4G(XMP) 4GB SS - - 9-9-9-
27
1.65 • • •
KINGSTON KHX1600C9D3K3/12GX(XMP) 12GB ( 3x 4GB ) DS - - 9 1.65 • •
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3K4/16GX(XMP) 16GB (4x 4GB) DS - - 9-9-9-
24
1.65 • • •
KINGSTON KHX1600C9D3K6/24GX(XMP) 24GB ( 6x 4GB ) DS - - 9 1.65 • • •
KINGSTON KHX1600C9D3LK2/8GX(XMP) 8GB (2x4GB) DS - - 9-9-9-
24
1.35 • • •
KINGSTON KHX1600C9D3P1K2/8G 8GB (2x4GB) DS - - 9 1.5 • • •
KINGSTON KHX16C10B1K2/16X(XMP) 16GB (2x8GB) DS - - - 1.5 • • •
KINGSTON KHX16C9K2/16 16GB (2x8GB) DS - - 1333-
9-9-9-
24
1.5 • • •
KINGSTON KHX16C9P1K2/16 16GB (2x8GB) DS - - - 1.5 • • •
KINGSTON KVR16N11/4 4GB DS KINGSTON D2568JPUCPGGBU 11-11-
11-
28-1
- • • •
KINGSTON KVR16N11/4 4G DS Hynix H5TQ2G83CFRPBC - 1.5 • • •
MICRON MT16JTF1G64AZ-1G6E1 8GB DS Micron D9QBJ - - • • •
MICRON MT8JTF51264AZ-1G6E1 4GB SS Micron D9QBJ - - • • •
MICRON MT8KTF25664AZ-1G6M1 2GB SS MICRON D9PFJ - - • • •
Patriot PV316G160C9K(XMP) 16GB (2x4GB ) SS - - 1600-
9-9-9-
24
1.5 • • •
Patriot PV316G160C9K(XMP) 16GB (2x8GB ) SS - - 1600-
9-9-9-
24
1.5 • • •
SanMax SMD-4G28N1P-16KM 4GB SS ELPIDA J4208BBBG-GN-F 1600 - • • •
SanMax SMD-4G68HP-16KZ 4GB DS Hynix H5TQ2G83BFRPBC - 1.5 • • •
SanMax SMD-4G68NG-16KK 4GB DS ELPIDA J2108BDBG-GN-F - - • • •
SanMax SMD-8G28NP-16KM 8GB DS ELPIDA J4208BBBG-GN-F 1600 - • • •
