Chapter 3

Allow Fan Stop 1/4 [Disabled]

These items allow the chassis fans to run at 0% duty cycle when the

temperature of the source is dropped below the lower temperature.

Conguration options: [Disabled] [Enabled]

ASST Fan 1/3 Q-Fan Control 1/3 [Enabled]

These items allow you to set the assistant fans’ Q-Fan control feature into DC Mode, PWM

Mode, or disable these Q-Fan controls from your motherboard.

Conguration options: [Disabled] [DC Mode] [PWM Mode]

The following items appear only when you set the Assistant Fan 1/3 Q-Fan Control to

[PWM Mode] or [DC Mode].

ASST Fan 1/3 Q-Fan Source [DC Mode]

This item controls the assigned fan according to the selected temperature source.

Conguration options: [CPU] [MB] [VCORE] [VCORE (BACK)] [DRAM] [PCH Core]

[USB3.0] [PCIE-1] [PCIE-2] [T_Sensor1] [T_Sensor2] [T_Sensor3]

If you select T_SENSOR 1/3, plug a thermistor cable to T_SENSOR 1/3 headers and stick

the thermistor cable’s head to the desired component as the temperature source.

ASST Fan 1/3 Speed Low Limit [300 RPM]

This item allows you to disable or set the assistant fans’ warning speed.

Conguration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]

ASST Fan 1/3 Profile [Standard]

This item allows you to set the appropriate performance level of the assistant fans.

[Standard] Set to make the assistant fan adjust automatically depending on the

chassis temperature.

[Silent] Set to minimize the fan speed for quiet assistant fan operation.

[Turbo] Set to achieve maximum assistant fan speed.

[Manual] Set to assign detailed fan speed control parameters.

The following items appear only when you set the ASST Fan 1/3 Prole to [Manual].

ASST Fan 1/3 Upper Temperature [70]

Use the <+> or <-> keys to adjust the upper limit of the CPU temperature.

The values range from 40°C to 90°C.

ASST Fan 1/3 Max. Duty Cycle(%) [100]

Use the <+> or <-> keys to adjust the maximum assistant fan duty cycle.

The values may differ via Qfan tuning.

ASST Fan 1/3 Middle Temperature [45]

Use the <+> or <-> keys to set the value for ASST Fan Middle

Temperature.

ASST Fan 1/3 Middle Duty Cycle(%) [60]

Use the <+> or <-> keys to adjust the chassis fan middle duty cycle. The

values may differ via Qfan tuning.
