ASUS SABERTOOTH Z97 MARK S

1-9

Chapter 1

Layout contents

Connectors/Jumpers/Slots Page

1. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 1-37

CPU, optional, chassis, and assistant fan connectors

(4-pin CPU_FAN; 4-pin CPU_OPT; 4-pin CHA_FAN1-4; 3-pin

ASST_FAN1-2, 4-pin ASST_FAN3)

1-35

3. LGA1150 CPU socket 1-10

4. DDR3 DIMM slots 1-11

5. MemOK! button 1-27

6. USB 3.0 connector (20-1 pin USB3_34) 1-32

Intel

Z97 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1-2

[black]; SATA6G_3-4 [black] SATA Express [black at the bottom])

1-31

8. CPU Over Voltage jumper (3-pin CPU_OV) 1-29

9. Clear RTC RAM (3-pin CLRTC) 1-28

10. DirectKey connector (2-pin DRCT) 1-39

11. System panel connector (20-8 pin PANEL) 1-38

12.

ASMedia

Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_E1-E2

[beige])

1-32

13. USB 2.0 connectors (10-1 pin USB1112, USB1314) 1-34

14. Thunderbolt header (5-pin TB_HEADER) 1-40

15.

Thermal sensor connectors (T_SENSOR1, T_SENSOR2,

T_SENSOR3)

1-36

16. Front panel audio connector (10-1 pin AAFP) 1-36

17. Digital audio connector (4-1 pin SPDIF_OUT) 1-33

18. TPM connector (20-1 pin TPM) 1-39
