Exclusive TUF Features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Armor with Flow Valve*
- TUF Thermal Radar 2 with Thermistors
- TUF ICe
“We Got Your Back” Shape Force
- TUF Fortier*
“TUF ENGINE” Power Design
- 8+2 Digital Phase Power Design
- TUF Components (10K Ti-Cap, New Alloy Choke and
MOSFET; certied by military-standard)
- ASUS DIGI+ Power Control Utility
“SAFE & Stable!” Guardian Angel
- Dust Defenders** with connector caps and rear I/O dust lter
- TUF ESD Guards
- MemOK!
* In snow camouflage theme.
** The Dust Defenders for the PCIe and DRAM slots comes in white color.
Other Special Features
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- USB BIOS Flashback with USB BIOS Flashback Wizard for EZ
BIOS download scheduling
- USB Charger+ featuring quick-charging function for all smart
devices
- ASUS Remote GO! with Cloud GO! Remote Desktop, Remote
Keyboard and Mouse, and File Transfer
- ASUS UEFI BIOS EZ Mode featuring user-friendly graphics user
interface
- Turbo LAN to experience smooth online gaming with lower pings
and less lags
- Push Notice monitors your PC status with smart devices in real
time
- AI Suite 3
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- ASUS EZ Update
- Disk Unlocker
- ASUS EZ Flash 2
- Multi-language BIOS
SABERTOOTH Z97 MARK S specifications summary
(continued on the next page)
