ASUS SABERTOOTH Z97 MARK S
4-9
Chapter 4
Thermal Status
Displaysthecurrentstatusofthethermalconditionofyoursystem.
Recorder
Displaysandmonitorsthestatusofthethermalsettingandconditionofyoursystem.
Click or tap to run the
assessment report of
your current thermal
settings.
Click or tap to scroll
down/up
Thermal Tuning
Thisfunctionoptimizesyoursystem’scoolingsolutionbasedonyoursystem’scurrent
thermalsettings.ItallowsyoutocongureyourCPU,chassis,andtheexclusiveTUFTurbo
fanstoachievethebestbalancebetweencoolingperformanceandlownoise.
Click or tap to
automatically start
the Thermal Tuning
process
