ASUS SABERTOOTH Z97 MARK S
1-13
Chapter 1
SABERTOOTH Z97 MARK S Motherboard Qualified Vendors Lists (QVL)
DDR3 3200 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
AVEXIR AVD3UH32001304G-4CI(XMP) 16GB ( 4x 4GB ) SS - - 13-15-
15-35
1.65V • •
G.SKILL F3-3200C12Q-16GTXDG(XMP) 16GB ( 4x 4GB ) SS - - 12-15-
15-35
1.65V • •
DDR3 3100 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
AVEXIR AVD3UH31001204G-4CI(XMP) 16GB ( 4x 4GB ) SS - - 12-14-
14-35
1.65V • •
A-DATA AX3U3100W4G12-DMV(XMP) 8GB ( 2x 4GB ) SS - - 12-14-
14-36
1.65V • •
DDR3 3000 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM
socket
support
(Optional)
2 4
AVEXIR AVD3UH30001204G-
4BZ1(XMP)
16GB ( 4x 4GB ) SS - - 12-14-
14-35
1.65V • •
G.SKILL F3-3000C12Q-16GTXDG(XMP) 16GB ( 4x 4GB ) SS - - 12-14-
14-35
1.65V • •
G.SKILL F3-3000C12D-8GTXDG(XMP) 8GB (2 x 4B ) SS 12-14-
14-35
1.65V • •
CORSAIR CMY8GX3M2A3000C12R(XMP) 8GB (2 x 4B ) SS 12-14-
14-36
1.65V •
