xii
SABERTOOTH Z97 MARK S specifications summary
Rear Panel I/O Ports
1 x DisplayPort
1 x HDMI port
1 x Optical S/PDIF Output
1 x USB BIOS Flashback button
2 x LAN (RJ45) port
4 x USB 3.0/2.0 ports (blue, 1 supports USB BIOS Flashback)
4 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Internal I/O connectors
2 x USB 3.0/2.0 connector support additional 4 USB 3.0/2.0 ports
(moss green)
2 x USB 2.0/1.1 connectors support additional 4 USB 2.0/1.1 ports
6 x SATA 6.0 Gb/s connectors (2 x black; 2 x black above the SATA
Express connector, 2 x beige)
1 x CPU Fan connector (moss green) supports both 3-pin (DC
mode) and 4-pin (PWM mode) CPU coolers control with auto
detection support
1 x CPU Optional Fan connector (white) supports both 3-pin (DC
mode) and 4-pin (PWM mode) CPU coolers control
4 x Chassis Fan connectors (white) supports both 3-pin (DC mode)
and 4-pin (PWM mode) CPU coolers control
3 x Assistant Fan connectors (2 x 3-pin, 1 x 4-pin [white])
Internal I/O connectors
1 x Front panel audio connector (AAFP)
1x 24-pin EATX Power connector
1x 8-pin EATX 12V Power connector
1 x System panel (Q-Connector)
1 x MemOK! button
1 x DRCT (DirectKey) connector
3 x Thermal Sensor (T_Sensor) headers
1 x S/PDIF out header
1 x TPM header
1 x 5-pin Thunderbolt header for ASUS ThunderboltEX series
support
1 x Clear CMOS jumper
BIOS features
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM
BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS
CrashFree BIOS 3, My Favorites, Quick Note, Last Modied Log,
F12 PrintScreen function, F3 Shortcut functions, and ASUS DRAM
SPD (Serial Presence Detect) memory information
Manageability
WfM 2.0, DMI 2.7, WOL by PME, PXE
Support DVD contents
Drivers
Anti-virus software (OEM version)
ASUS/TUF CPU-Z
ASUS Utilities
Form factor
ATX form factor: 12.0 in. x 9.6 in. (30.5 cm x 24.4 cm)
Specications are subject to change without notice.
