ASUS SABERTOOTH Z97 MARK S
4-15
Chapter 4
2. AftertheutilitydetectsanewBIOS,
clickortap fromtheSaveto:eld,
selecttheUSBashdrive,thenclick
ortapDownload.
Downloading the latest BIOS
Beforeyoustartdownloading,ensurethatyouhaveinstalledtheUSBstoragedevice
toyourcomputer’sUSBportthatsupportsUSBBIOSFlashback.RefertotheRear I/O
connectionsectionofthisuserguideformoredetails.
TodownloadtheupdatedBIOS:
1. FromtheUSBBIOSFlashbackscreen,
clickortapCheck for New BIOS
Update.
Waitforthesystemtocheckthelatest
BIOSversion.
3. Afterthedownloadiscomplete,clickor
tapOK.
