4-10
Chapter 4: Software support
Chapter 4
DIGI+ Power Control
ASUSDIGI+PowerControlfeaturestherevolutionaryandinnovativedigitalVRMandDRAM
Voltagecontrollers.Thesecontrollersoffersultra-precisememoryandvoltagetuningfor
optimalsystemefciency,stabilityandperformance.
DIGI+PowerControl - CPU
DIGI+PowerControl - DRAM
Click or tap to switch
between items
Click or tap to go back
to the previous screen
Click or tap to undo
the changes
Click or tap to apply
the changes
Click or tap to go the
CPU configurations
screen
Click or tap to go the
DRAM configurations
screen
Click or tap to undo
the changes
Click or tap to apply
the changes
Click or tap to go back
to the previous screen
