Asus tuf sabertooth z97 mark s [14/176] Installation tools and components

xiv

Installation tools and components

1 bag of screws Philips (cross) screwdriver

PC chassis Power supply unit

Intel

LGA1150 CPU Intel

LGA1150 compatible CPU Fan

DIMM SATA hard disk drive

SATA optical disc drive (optional) Graphics card (optional)

The tools and components in the table above are not included in the motherboard package.
