Asus ts700-e7-rs8 [103/198] Serial port console redirection

TS700-E7/RS8

5-33

Chapter 5

5.4.14 Serial Port Console Redirection

COM1

Console Redirection [Disabled]

Allows you to enable or disable the console redirection feature.

Conguration options: [Disabled] [Enabled]

The following item appears only when you set Console Redirection to [Enabled].

Console Redirection Settings

This item becomes congurable only when you enable the Console Redirection

item. The settings specify how the host computer and the remote computer (which

the user is using) will exchange data. Both computers should have the same or

compatible settings.

Terminal Type [VT-UTF8]

Allows you to set the terminal type.

[VT100] ASCII char set.

[VT100+] Extends VT100 to support color, function keys, et.

[VT-UTF8] Uses UTF8 encoding to map Unicode chars onto 1 or more

bytes

[ANSI] Extended ASCII char set

COM1

Console Redirection [Disabled]

Console Redirection Settings

COM2

Console Redirection [Enabled]

Console Redirection Settings

Serial Port for Out-of-Band Management/

Windows Emergency Management Services (EMS)

Console Redirection [Disabled]

Console Redirection Settings

Console Redirection Enable

or Disable.

Advanced

→←: Select Screen

↑↓: Select Item

Enter: Select Item

+/-: Change Opt.

F1: General Help

F2: Previous Values

F5: Optimized Defaults

F10: Save & Exit

ESC: Exit
