5-40
Chapter 5: BIOS setup
Chapter 5
5.5.2 BMC network conguration
Conguration Address source [Previous State]
Allows you to select the static or dynamic LAN settings.
Conguration options: [Previous State] [Static Mode] [DHCP Mode]
The following items appear only when you set Conguration Address source to
[Static Mode].
Station IP address [0.0.0.0]
Allows you to key in the Station IP address.
Subnet mask [0.0.0.0]
Allows you to key in the Subnet mask.key in the Subnet mask. Subnet mask.
Gateway IP address [0.0.0.0]
Allows you to key in the Gateway IP address.key in the Gateway IP address. Gateway IP address.
Select to congure LAN
channel parameters
statically or
dynamically(by BIOS or
BMC). Unspecied option
will not modify any BMC
network parameters during
BIOS phase
BMC network conguration
DM_KAN1
DM_LAN1 IP Address in BMC: 192.168.001.001
DM_LAN1 Subnet Mask in BMC: 255.255.255.000
DM_LAN1 Gateway Address in BMC :000.000.000.000
DM_LAN1 MAC Address in BMC: 00.CE.01.87.72.A0
DM_LAN1 Address Source in BMC: Static Mode
Conguration Address source [Previous State]
Lan1
Lan1 IP Address in BMC: 192.168.001.002
Lan1 Subnet Mask in BMC: 255.255.255.000
Lan1 Gateway Address in BMC: 000.000.000.000
Lan1 MAC Address in BMC: 00.CE.01.87.72.A0
Lan1 Address Source in BMC: Static Mode
Conguration Address source [Previous State]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Server Mgt
