Asus ts700-e7-rs8 [19/198] Chapter 1

TS700-E7/RS8

1-7

1.6.2 Rear panel LEDs

ACT/LINK LED SPEED LED

Status Description Status Description

OFF No link OFF 10 Mbps connection

GREEN Linked ORANGE

100 Mbps

connection

BLINKING Data activity GREEN 1 Gbps connection

SPEED LED

ACT/LINK LED

Chapter 1
