Asus ts700-e7-rs8 [156/198] Chapter 6

6-36

Chapter 6: RAID conguration

Chapter 6

• If you hard disk contains data and you do not want to keep this data, click

NO in the next column if it is displayed.

• �ou can enable the volume write-cache or volume initialization function�ou can enable the volume write-cache or volume initialization functioninitialization functionfunction

from the Advanced tab.

6. Conrm the volume creation, than click Create Volume to continue.

This process could take a while depending on the number and size of the disks.

You can contuine using other applications during this time.

Click OK when nished.

You still need to partition your new volume using Windows Disk Management

before adding any data.
