6-24
Chapter 6: RAID conguration
Chapter 6
6.3 Intel
®
Rapid Storage Technology enterprise SCU/
SATA Option ROM Utility
The Intel
®
Rapid Storage Technology enterprise SCU / SATA Option ROM utility
allows you to create RAID 0, RAID 1, RAID 10 (RAID 1+0), and RAID 5 set(s)
from Serial ATA hard disk drives that are connected to the Serial ATA connectors
supported by the Southbridge.
You can create RAID mode by use of onboard AHCI SATA ports.
To use onboard SATA ports:
1. Install all the Serial ATA hard disk drives.
2. Turning on the system. During POST, press,Del. to enter BIOS. Go to
Advanced Menu > PCH SATA Conguration > SATA Mode, then press
<Enter>.
3. Set SATA Mode to RAID Mode and save, then reboot system.
4. During POST, press <Ctrl+I> to display the utility main menu.
To use SCU SATA ports:
1. Install all the hard disk drives.
2. Turn on the system.
3. Conrm all the SATA hard disk drives you installed are correctly displayed,
then reboot system.
4. During POST, press <Ctrl+I> to display the utility main menu.
