5-12
Chapter 5: BIOS setup
Chapter 5
Hardware Prefetcher [Enabled]
Allows you to turn on/off the mid level cache(L2) streamer prefetcher.Conguration
options: [Disabled] [Enabled]
Adjacent Cache Line Prefetch [Enabled]
Allows you to turn on/off prefetching of adjacent cache lines.
Conguration options: [Disabled] [Enabled]
DCU Streamer Prefetcher [Enabled]
Allows you to enable or disable prefetcher of next L1 data line.
Conguration options: [Disabled] [Enabled]
DCU IP Prefetcher [Enabled]
Allows you to enable or disable prefetch of next L1 line based upon sequential load
history. Conguration options: [Disabled] [Enabled]
Intel
®
Virtualization Technology [Enabled]
When this item is enabled, a VMM can utilize the additional hardware capabilities
provided by Vanderpool Technology. Conguration options: [Disabled] [Enabled]
Local APIC Mode [Disabled]
Select the Local APIC mode. If Auto, use x2APIC if required. Otherwise, use xAPIC
mode. xAPIC will disable CPUs with APIC IDs greater than 254. Some OS do not
support x2APIC mode. Conguration options: [Disabled] [Enabled]
