Asus ts700-e7-rs8 [12/198] Ts700 e7 rs8 specifications summary

xii

TS700-E7/RS8 specications summary

Net Weight Kg (CPU, DRAM &

HDD not included)

20 Kg

Power Supply

1+1 Redundant 800W 80PLUS

Gold Power Supply

(following different conguration by region)

or 1+1 Redundant 620W Power Supply

(for Taiwan only)

Power Supply Rating Output

800W: 100-127 / 200-240 Vac,

9.9A / 4.79A, 47-63 Hz, Class 1

620W (for Taiwan only): 100-240 Vac,

10A, 50-60 Hz, Class 1

Environment

Operating temperature: 10℃ ~ 35℃

Non operating temperature: -40℃ ~ 70℃

Non operating humidity: 20% ~ 90%

(Non condensing)

Specications are subject to change without notice.
