TS700-E7/RS8
7-7
Chapter 7
4. Insert the Red Hat
®
Enterprise RAID driver disk to the USB oppy disk drive,
select OK, then press <Enter>.
The drivers for the RAID card are installed to the system.
5. When asked if you will load additional RAID controller drivers, select No, then
press <Enter>.
Insert Driver Disk
Insert your driver disk into /dev/fd0 and
press “OK” to continue.
OK
Back
Yes No
6. Follow the onscreen instructions to nish the OS installation.
7. When the installation is completed, DO NOT click Reboot. Press <Ctrl> +
<Alt> + <F2> to switch to the command-line interface from graphic user
interface.
8. Type the following commands when using a legacy oppy disk.
mkdir /mnt/driver
mount /dev/fd0 /mnt/driver
cd /mnt/driver
sh replace_ahci.sh
reboot
More Driver Disks?
Do you wish to load any more driver
disks?
