Asus ts700-e7-rs8 [15/198] Front panel features

TS700-E7/RS8

1-3

1.3 Front panel features

*The audio jacks function only with an optional MIO audio card.

Refer to section 1.6.1 Front panel LEDs for the LED descriptions.

Optical drive

Empty 5.25-inch

bays

Power button

Reset button

Message LED

HDD access LED

Power LED

USB 2.0 ports

Security lock

4-bay HDD cage

LAN1 LED

LAN2 LED

Headphone

output jack*

Microphone jack

4-bay HDD cage

Locate LED

(Reserved)

Chapter 1
