Nec U250X [13/82] Introduction
![Nec U250X [13/82] Introduction](/views2/1205524/page13/bgd.png)
6
English ...
Introduction
1. Lamp Cover
2. Ventilation (outlet)
3. Control Panel
4. Mirror
5. Cable Cover
6. Release rings for Cable
Cover
7. Kensington
TM
Lock Port
(This security slot sup-
ports the MicroSaver
®
Projector
Product Overview
13
2
6
11
10
7
8
6
5
1
3
4
12
2
9
Security System)
8. Tilt Adjusting Feet
9. Ventilation (inlet)
10. Lens
11. Focus Lever
12. Remote Sensor
13. Speaker
