69
... English
Appendices
Cabinet Dimensions
Ventilation
Ventilation
Focus Level
Lens Center
200.00
388.00
255.50
217.00
405.76
427.00
326.80
66.38 124.84
75.3538.87
200.00
10.00
21.2889.44
133.78 108.94
148.48
-A-
Unit: mm
