21
... English
Introduction
Step 1: Install PC Control Utility Pro 4 on the computer
• Supported OS - PC Control Utility Pro 4 will run on the following
operating systems.
Windows 7 Home Basic *1, Windows 7 Home Premium *1, Windows 7
Professional *1, Windows 7 Enterprise *1, Windows 7 Ultimate *1
Windows Vista Home Basic *1, Windows Vista Home Premium *1, Windows
Vista Business *1, Windows Vista Enterprise *1, Windows Vista Ultimate
*1
Windows XP Home Edition *2, Windows XP Professional *2
*1: Supports 32-bit version.
*2: To run PC Control Utility Pro 4, “Microsoft .NET Framework Version 2.0
or later” is required. The Microsoft .NET Framework Version 2.0 or later is
available from Microsoft’s web page. Install the Microsoft .NET Framework
Version 2.0 or later on your computer.
1 Download the updated VRT exe le from our web site (http://www.nec-
display.com/dl/en/index.html).
2 Double-click the VRT. exe icon.
The Installer will start and the Wizard screen will appear.
3 Click “Next”.
“END USER LICENSE AGREEMENT” screen will be displayed.
To install or unin-
stall the program, the
Windows user account
must have [Admin-
istrator] privilege
(Windows 7, Windows
Vista and Windows
XP)
Exit all running
programs before
installation. If another
program is running,
the installation may
not be completed.
