Introduction
17 Number Button Select password.
18 CLEAR Clear the number while you
input the password.
19 FREEZE Freeze To pause the screen im-
age. Press again to resume the
screen image.
20 EXIT Exit the settings.
21 ENTER Conrm your section of items in
sub menu operation.
22 Four
Directional
Select Buttons
Use or or or to select
items or make adjustments to
your selection.
23 PAGE Use this button to page up or
page down.
24 R-CLICK Mouse right click.
25 PICTURE
Mode
Select the Picture mode from
Presentation, Movie, sRGB,
Game and User.
26 VOL. +/- Increase/decrease speaker vol-
ume.
27 ASPECT Use this function to choose your
desired aspect ratio. (refer to
page 38)
