64
English ...
Appendices
Specications
Optical
U300X U250X U310W U260W
Projection System Single DLP® chip (0.55”, aspect ratio 4:3) Single DLP® chip (0.65”, aspect ratio
16:10)
Resolution
*1
1024 × 768 pixels (XGA) 1280 × 800 pixels (WXGA)
Lens Manual focus
F2.71
Lamp 280W AC
(245W in ECO
mode)
230W AC
(190W in ECO
mode)
280W AC
(245W in ECO
mode)
230W AC
(190W in ECO
mode)
Light Output
*2 *3
3000 lumens 2500 lumens 3100 lumens 2600 lumens
Approx. 80% in ECO mode
Contrast Ratio
*3
(full white:full black)
2000:1
Image Size (Diagonal) 63 to 85 inches/ 1.6 to 2.16 m 77 to 100 inches/ 1.96 to 2.54 m
Projection Distance
(mini. - max.)
5.1 to 12.3 inches / 0.13 to 0.31m 5.8 to 12.2 inches / 0.15 to 0.31 m
Projection Angle 55.3°
*1 Effective pixels are more than 99.99%.
*2 This is the light output value (lumens) when [Picture Mode] is set to [High-Bright] in the menu. If any other
mode is selected as [Picture Mode], the light output value may drop slightly.
*3 Compliance with ISO21118-200
Electrical
U300X U250X U310W U260W
Inputs 2 x RGB/Component (D-Sub 15P), 1 x HDMI (19P) HDCP supported
*4
, 1 x S-Video
(DIN 4P), 1 x Video (RCA), 1 x (L/R) RCA Audio, 2 x Stereo Mini Audio
Outputs 1 x RGB (D-Sub 15P), 1 x Stereo Mini Audio
PC Control 1 x PC Control Port (D-Sub 9P)
Wired LAN Port 1 x RJ-45 (10/100 BASE-T)
Service Port 1 x mini USB (for service purpose only)
Color Reproduction 16.7 million colors simultaneously, Full color
Compatible Signals
*5
Analog: VGA/SVGA/XGA/XGA+/WXGA/Quad-VGA/WXGA+/SXGA/SXGA+/
WXGA+/WXGA++/UXGA
480i/480p/576i/576p/720p/1080i/1080p
HDMI: VGA/SVGA/XGA/WXGA/Quad-VGA/SXGA/SXGA+/WXGA+/
WXGA++/
480p/576p/720p/1080i/1080p
Video Bandwidth RGB: 80 MHz (Max.)
Horizontal Resolution 540 TV lines: NTSC/NTSC4.43/PAL/PAL-M/PAL-N/PAL60
300 TV lines: SECAM
Scan Rate Horizontal: 31.35 kHz to 91.1 kHz
Vertical: 56 Hz to 120 Hz (HDMI: 50 to 85 Hz)
