Nec U250X [35/82] Adjusting the projected image
![Nec U250X [35/82] Adjusting the projected image](/views2/1205524/page35/bg23.png)
28
English ...
Installation
0.45”/
11.46mm
Adjusting the Projected Image
Adjusting the Height of Projector Image
The projector is equipped with adjustable feet to raise and lower
the image to ll the screen.
1. Rotate the tilt adjustable feet counter clockwise to raise the
projector or clockwise to lower it. Repeat with the remain-
ing feet as needed.
Tilt adjusting feet
