![Nec U250X [65/82] Appendices](/views2/1205524/page65/bg41.png)
58
English ...
Appendices
Problem: LED lighting message
Power Indicator
Indicator Condition Projector Condition Note
Off The main power is off --
Blinking light Blue 0.5 sec On,
0.5 sec Off
The projector is getting ready to turn on. Wait for a moment.
2.5 sec On,
0.5 sec Off
Off Timer is enabled. --
Steady light Blue The projector is turned on. --
Orange “Normal” is selected for “Standby Mode” --
Red “Power-Saving” is selected for “Standby Mode” --
Status Indicator
Indicator Condition Projector Condition Note
Off Normal or Standby (“Power-Saving” for “Standby
Mode”)
--
Blinking light Red 1 cycle (0.5 sec
On, 2.5 sec Off)
Lamp cover error or lamp housing error Replace the lamp cover or lamp housing correctly.
2 cycle (0.5 sec
On, 0.5 sec Off)
Temperature error The projector is overheated. Move the projector to a
cooler location.
3 cycle (0.5 sec
On, 0.5 sec Off)
Power error Power unit is not working properly. Contact your dealer.
4 cycle (0.5 sec
On, 0.5 sec Off)
Fan error Fans will not work correctly.
6 cycle (0.5 sec
On, 0.5 sec Off)
Lamp error Lamp fails to light. Wait a full minute and then turn
on again.
Green Re-ring the lamp (The projector is cooling down) The projector is re-ring.
Wait for a moment.
Steady light Green Standby (“Normal” for “Standby Mode”) --
Orange CONTROL PANEL LOCK is on. You have pressed cabinet button when Control Panel
Lock is on.
Lamp Indicator
Indicator Condition Projector Condition Note
Off Normal --
Blinking light Red Lamp has reached its end of life. Lamp replace-
ment message will be displayed.
Replace the lamp.
Steady light Red Lamp has reached its end of life. The projector will
not turn on until the lamp is replaced.
Wait for a moment.
Green “ECO Mode” is set to “On” --
