![Nec U250X [69/82] Appendices](/views2/1205524/page69/bg45.png)
62
English ...
Appendices
Warning: To reduce the
risk of personal injury,
do not drop the lamp
module or touch the
lamp bulb. The bulb
may shatter and cause
injury if it is dropped.
Lamp Replacing Procedure:
1. Switch off the power to the projector by pressing the POWER
OFF button on the remote control or the button on the
control panel.
2. Allow the projector to cool down at least 60 minutes.
3. Disconnect the power cord.
4. Use a screwdriver to remove the screw from the cover.
5. Push up and remove the cover.
6. Remove 3 screws from the lamp module and pull up the
handle.
7. Pull out the lamp module.
8. Install the new lamp module by reversing the previous steps.
Be sure to tighten the screws on the lamp module and the
lamp cover.
9. After replacing the lamp, turn on the power, and select the
[MENU] button -> OPTIONS | Lamp Settings -> Clear Lamp
Hours to reset the lamp usage hours. Refer to page 52.
Do not break the glass
on the lamp housing.
Keep nger prints off
the glass surface on the
lamp housing. Leaving
nger prints on the
glass surface might
cause an unwanted
shadow and poor
picture quality.
