Introduction
Remote Control
1 POWER ON Power on the projector. Refer to
the “Power On/Off the Projec-
tor” section on pages 25-26.
2 POWER OFF Power off the projector.Refer to
the “Power On/Off the Projec-
tor” section on pages 25-26.
