11
... English
Introduction
3 COMPUTER 1 Press “1” to choose COMPUTER
1 IN connector.
4 COMPUTER 2 Press “2” to choose COMPUTER
2 IN connector.
5 VIDEO Press “VIDEO” to choose VIDEO
IN connector.
6 NUM Select password. When you
input a password, you must
press “NUM” and other number
button simultaneously.
7 AV-MUTE Momentarily turn off/on the
audio and video.
8 MENU Press “MENU” to launch the
Onscreen display (OSD), back to
the top level of OSD for the OSD
main menu operation
9 D-ZOOM Zoom in/out the projected im-
age.
10 L-CLICK Mouse left click.
11 KEYSTONE
Correction
Adjust the image to compensate
for distortion caused by tilt-
ing the projector (vertical ± 40
degrees).
12 ECO Dim the projector lamp which
will lower power consumption
and extend the lamp life. (refer
to page 52)
13 HELP This function ensures easy setup
and operation.
14 AUTO ADJ. Automatically synchronize the
projector to the input source.
15 S-VIDEO Press “S-VIDEO” to choose S-
VIDEO IN connector.
16 HDMI Press “HDMI” to choose HDMI
IN connector.
