![Nec U250X [72/82] Mechanical](/views2/1205524/page72/bg48.png)
65
... English
Appendices
Sync Compatibility Separate Sync
Built-in Speaker 10W (monaural)
Power Requirement 100 – 240V AC, 50/60 Hz
Input Current 100 – 240V AC,
50-60Hz, 3.5-1.5A
100 – 240V AC,
50-60Hz, 3.0-1.3A
100 – 240V AC,
50-60Hz, 3.5-1.5A
100 – 240V AC,
50-60Hz, 3.0-1.3A
Power Consumption
ECO Mode Off 315W+/-10%
@110Vac
245W+/-10%
@110Vac
315W+/-10%
@110Vac
245W+/-10%
@110Vac
ECO Mode On 360W+/-10%
@110Vac
300W+/-10%
@110Vac
360W+/-10%
@110Vac
300W+/-10%
@110Vac
Standby (Normal) 3 W
Standby (Power-
saving)
0.5 W
*4 HDMI
®
(Deep Color, Lip Sync) with HDCP
What is HDCP/HDCP technology?
HDCP is an acronym for High-bandwidth Digital Content Protection. High bandwidth Digital Content Protec-
tion (HDCP) is a system for preventing illegal copying of video data sent over a Digital Visual Interface (DVI).
If you are unable to view material via the HDMI input, this does not necessarily mean the projector is not
functioning properly. With the implementation of HDCP, there may be cases in which certain content is pro-
tected with HDCP and might not be displayed due to the decision/intention of the HDCP community (Digital
Content Protection, LLC).
*5 An image with higher or lower resolution than the projector’s native resolution (U300X/U250X: 1024 × 768
and U310W/U260W: 1280 × 800) will be displayed with scaling technology.
Mechanical
U300X U250X U310W U260W
Installation Orientation Desktop/Front, Desktop/Rear, Ceiling/Front, Ceiling/Rear
Dimensions 12.9” (W) × 5.5” (H) × 15.5” (D) /327 mm (W) × 138 mm (H) × 393 mm (D)
(not including protrusions)
16.8” (W) × 7.9” (H) × 16.0” (D) /427 mm (W) × 200 mm (H) × 406 mm (D)
(with cable cover and tilt adjusting wheel)
Weight 14.3 lbs/6.5 kg
Environmental Consid-
erations
Operational Temperatures : 41° to 104°F (5° to 40°C),
(ECO mode selected automatically at 95°F to 104°F/35°C to 40°C)
20% to 80% humidity (non-condensing)
Storage Temperatures : 14° to 122°F (-10° to 50°C),
20% to 80% humidity (non-condensing)
Regulations UL/C-UL Approved (UL 60950-1, CSA 60950-1)
Meets DOC Canada Class B requirements
Meets FCC Class B requirements
Meets AS/NZS CISPR.22 Class B
Meets EMC Directive (EN55022, EN55024, EN61000-3-2, EN61000-3-3)
Meets Low Voltage Directive (EN60950-1, TÜV GS Approved)
Electrical
U300X U250X U310W U260W
