Tp-Link T1600G-28PS (TL-SG2424P) [11/269] Package contents

Package Contents

The following items should be found in your box:

 One JetStream Gigabit Smart Switch

 One power cord

 Two mounting brackets and other fittings

 Installation Guide

 Resource CD for T1600-28TS/T1600G-52TS/T1600G-28PS/T1600G-52PS, including:

• This User Guide

• CLI Reference Guide

• SNMP Mibs

• 802.1X Client Software and its User Guide

• Other Helpful Information

Note:

Make sure that the package contains the above items. If any of the listed items are damaged or

missing, please contact your distributor.
