The following entries are displayed on this screen:



VLAN of Port

VLAN ID

：

Displays the ID number of VLAN.

Name:

Displays the user-defined description of VLAN.

Operation: Allows you to remove the port from the current VLAN.

Configuration Procedure:

Step Operation Description

Configure the PVID. Optional. On the VLAN→802.1Q VLAN→Port Config page,

configure the PVID of the port basing on its connected device.

Create VLAN. Required. On the VLAN→802.1Q VLAN→VLAN Config page,

click the Create button to create a VLAN. Enter the VLAN ID and

the name for the VLAN. Meanwhile, specify its member ports and

the link type of the ports.

Modify/View VLAN. Optional. On the VLAN→802.1Q VLAN→VLAN Config page,

click the Edit/Detail

button to modify/view the information of the

corresponding VLAN.

Delete VLAN Optional. On the VLAN→802.1Q VLAN→VLAN Config page,

select the desired entry to delete the corresponding VLAN by

clicking the Delete button.

6.2 Application Example for 802.1Q VLAN

 Network Requirements

 Switch A is connecting to PC A and Server B;

 Switch B is connecting to PC B and Server A;

 PC A and Server A is in the same VLAN;

 PC B and Server B is in the same VLAN;

 PCs in the two VLANs cannot communicate with each other.
