170
Note:
1. Up to 7 absolute time-ranges and 7 periodic time-ranges can be created in one Time-range.
2. If there is no entry in the Absolute Time table, the Absolute Time-range is from
2000/01/01-00:00 to 2099/12/31-24:00 by default.
3. If there is no entry in the Periodic Time table, the Periodic Time-range takes effect all the time
from Monday to Sunday by default.
The following items are displayed on this screen:
Time Range Config
Name: Enter the name of the time-range for time identification.
Holiday: Select Holiday mode. By default, the mode is Include.
Include: The Holiday has no effect on the Time-range
, which
means the final Time-
range will be the intersection of the Absolute
Time and Periodic Time.
Exclude:
The final Time range will be the intersection of the
Absolute Time and the Periodic Time, with Holiday excluded.
Add Absolute or Periodic
Type: Select the time range type, Absolute or Periodic.
Absolute: Absolute Time-range defines up to 7 time ranges with
specific
starting time and ending time in the Gregorian calendar. It
does not
recur.
From Time: Set the start time of the absolute time range.
To Time: Set the end time of the absolute time range.
Periodic: Periodic Time-range defines up to 7 time ranges with
specific
starting time and ending time in a week. Periodic Time-
range recurs
periodically on the day/days you configured in the week.
Start Time: Set the start time of the periodic time range.
End Time: Set the end time of the periodic time range.
Day of the Week: Select the recurring days in the periodic time range.
Absolute Time Table
Index: Displays the index of the absolute time range.
From Time: Displays start time of the absolute time range.
To Time: Displays end time of the absolute time range.
Operation: Click the Delete button to delete the corresponding time range.
Periodic Time Table
Index: Displays the index of the periodic time range.
Start Time: Displays the start time of the periodic time range.
End Time: Displays the end time of the periodic time range.
Day of the Week: Displays the recurring days in the periodic time range.
