Hitachi DV16V [6/42] English

English

4. Selecting the appropriate drill bit

䡬 When boring concrete or stone

Use the drill bits specified in the Optional Accessories.

䡬 When boring metal or plastic

Use an ordinary metalworking drill bit.

䡬 When boring wood

Use an ordinary woodworking drill bit.

However, when drilling 6.5 mm or smaller holes, use

a metalworking drill bit.

5. Mounting and dismounting of the bit

For Drill chuck with chuck wrench (Fig. 1)

(1) Open the chuck jaws, and insert the bit into the

chuck.

(2) Place the chuck wrench in each of the three holes

in the chuck, and turn it in the clockwise direction

(viewed from the front side). Tighten securely.

(3) To remove the bit, place the chuck wrench into one

of the holes in the chuck and turn it in the

counterclockwise direction.

For keyless chuck (Fig. 2)

(1) Open the chuck jaws, and insert the bit into the

chuck.

To open the chuck jaws, hold the ring while turning

the sleeve in the counterclockwise direction (viewed

from the front side).

(2) Firmly grasp the ring and turn the sleeve in the

clockwise direction. Tighten securely.

(3) To remove the bit, firmly grasp the ring and turn the

sleeve in the counterclockwise direction.

(4) When the sleeve does not become loose any further,

fix the side handle to retaining ring, hold side handle

firmly, then turn the sleeve to loosen by hand (Fig. 3).

6. Check the rotational direction (Fig. 4)

The bit rotates clockwise (viewed from the rear side)

by pushing the R-side of the push button.

The L-side of the push button is pushed to turn the bit

counterclockwise.

(The

and

marks are provided on the body.)

CAUTION

Always use the impact drill with clockwise rotation,

when using it as an impact drill.

Voltage (by areas)* (110V, 220V, 230V, 240V)

Power input 590 W*

No load speed 0–2900 min

-1

Drill chuck capacity 13 mm

Steel 13 mm

Concrete 16 mm

Wood 25 mm

Full load impact rate 34500 min

-1

Weight (without cord) 1.5 kg

STANDARD ACCESSORIES

(1) Chuck Wrench (Spec. only for chuck fitted with chuck

wrench) ...................................................................... 1

(2) Side Handle................................................................ 1

(3) Depth Gauge .............................................................. 1

(4) Plastic case................................................................. 1

Standard accessories are subject to change without

notice.

OPTIONAL ACCESSORIES (sold separately)

(1) Impact Drill Bit (for concrete)

3.2 mm – 20 mm dia.

(2) Hook (A)

Optional accessories are subject to change without notice.

APPLICATIONS

䡬 By combined actions of ROTATION and IMPACT:

Boring holes in hard materials (concrete, marble,

granite, tiles, etc.)

䡬 By ROTATIONAL action:

Boring holes in metal, wood and plastic.

PRIOR TO OPERATION

1. Power source

Ensure that the power source to be utilized conforms

to the power requirements specified on the product

nameplate.

2. Power switch

Ensure that the power switch is in the OFF position. If

the plug is connected to a receptacle while the power

switch is in the ON position, the power tool will start

operating immediately, inviting serious accident.

3. Extension cord

When the work area is removed from the power

source. Use an extension cord of sufficient thickness

and rated capacity. The extension cord should be

kept as short as practicable.

SPECIFICATIONS

*Be sure to check the nameplate on product as it is subject to change by areas.

Capacity
