GRAPHITE 59G207 [15/118] Operation adjustments

DESCRIPTION OF USED GRAPHIC SIGNS

NOTE

WARNING

FITTING/SETTING

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Grinding wheel guard - 1 pce

2. Socket spanner - 1 pce

3. Additional handle - 1 pce

PREPARATION FOR WORK

ATTACHING THE ADDITIONAL HANDLE

The additional handle (3) is installed in one of the holes in the

grinder head. It is recommended to use the grinder with the

additional handle. When holding the grinder with both hands

(also using the additional handle), there is less risk of touching

the grinder wheel or brush with your hand, as well as of injuries

during recoil.

ADJUSTABLE MAIN HANDLE

Before starting operation you can adjust the main handle to the

position most comfortable for the task. Before starting operation

you can adjust the main handle to the position most comfortable

for the task. The handle can be fixed in 3 different positions

by rotating it by 90º to the left or right in relation to the base

position.

• Press the main handle lock button (9) (fig. D).

• Rotate the main handle to a desired position.

• The main handle will automatically lock in the position.

INSTALLING AND ADJUSTING THE GRINDING WHEEL

GUARD

The wheel guard protects the operator against flying broken

pieces and accidental contact with a working tool or sparks.

The guard should always be fitted. Special attention should be

paid so that its covering part faces the operator.

The design of the wheel guard mounting allows for toolless

setting of the guard in an optimum position.

• Loosen and pull back the lever (10) on the wheel guard (4).

• Rotate the wheel guard () in a selected position.

• Lock by lowering the lever (10).

The removal and adjustment of the wheel guard are performed

in a reverse order to its installation.

REPLACEMENT OF WORKING TOOLS

When working tools are replaced, wear working gloves at all

times.

The spindle lock button (1) is only designed to lock the grinder

spindle, when a working tool is installed or removed. Do not

use it as a braking button, when the wheel rotates. Otherwise,

the grinder may become damaged or the user may be injured.

INSTALLING THE WHEELS

When grinding or cut-off wheels with the thickness below

3 mm are installed, the outer flange nut (5) should be

tightened with the flat surface from the wheel side (fig. B).

• Press the spindle lock button (1).

• Insert the special key (included) into two holes of the outer

flange (5) (fig. A).

• Rotate the key to loosen and remove the outer flange (5).

• Place the wheel so it is pressed against the surface of the inner

flange (6).

• Tighten the outer flange (5) and slightly tighten it with the

special key.

The wheel is removed in the reverse order. During installation,

the wheel should be pressed against the surface of the inner

flange (6) and seated centrally in the neck.

INSTALLING THE WORKING TOOLS WITH THREADED HOLES

• Press the spindle lock button (1).

• Remove a previously installed working tool, if it is installed.

• Both flanges should be removed before installation – the inner

flange (6) and outer flange (5).

• Put the threaded part of a working tool onto the spindle and

slightly tighten.

Working tools with threaded holes are removed in the reverse

order.

INSTALLING THE ANGLE GRINDER ON A TRIPOD FOR

ANGLE GRINDERS

The angle grinder can be used on a dedicated tripod for angle

grinders, provided that it is correctly installed according to

instructions of the manufacturer of a tripod.

OPERATION / ADJUSTMENTS

Before the grinder is used, check condition of the grinding

wheel. Do not use chipped, broken or otherwise damaged

grinding wheels. Worn grinding wheel or brush should be

immediately replaced with new one before use. Once your

work is completed, you should switch off the grinder and wait

until it comes to a complete stop. Only then the grinder can be

put aside. Do not brake a rotating grinding wheel by pressing

it against a workpiece.

• Do not overload the grinder. The weight of the power

tool exerts sufficient pressure to efficiently work with

the tool. Overloading and excessive pressure may lead to

dangerous cracking of the working tool.

• If the grinder is dropped during operation, it should be

checked and a working tool might need to be replaced,

when it is damaged or deformed.

• Never strike the workpiece with a working tool.

• Do not use the grinding wheel for hammering or stripping

of the workpiece, especially when corners, sharp edges are

worked, etc. (this may cause loss of control of the power

tool and recoil).

• Do not use discs from circular saws intended for wood

cutting. Failure to observe this recommendation may

result in recoil of the power tool, loss of control and may

lead to injuries of the operator.

SWITCHING ON /SWITCHING OFF

When the grinder is switched on and operated, it should be

held with both hands. The grinder is equipped with the switch

protecting against accidental activation.

• Move the lever switch (7) forward.

• Press the switch button (2) (fig. C).

• When the switch button (2) is released, the grinder stops.

Motor starts operation with soft-start, which is used for

starting the motor without load.

Once the grinder is switched on, wait until the grinding wheel

reaches maximum speed and only then you can begin to work.
