127D-Link DIR-685 User Manual
Section 6 - File Sharing
In the Browse for Folder window, expand
Microsoft Windows Network > Workgroup
> DIR-685 and click on the folder you will
use for FTP le transfers.
Click OK to set the folder.
Click the Next button to
proceed to the next window.
