128D-Link DIR-685 User Manual
Section 6 - File Sharing
Type a name to easily identify the DIR-685
Network Place.
Click the Next button to proceed to the next
setup window.
The following window appears to indicate that the Add Network
Place Wizard has completed.
Tick the Open this network place when I click Finish checkbox
if you want to view the FTP directory on the DIR-685.
Click the Finish button to nish setting up the FTP directory.
