![D-Link DSM-G600 [13/74] Connect now wcn](/views2/1045701/page13/bgd.png)
13
DSM-G600 User’s Manual
D-Link Systems, Inc.
Note: This feature is only available through Windows XP with Service Pack 2 installed.
In this section, you will learn how to use the Wireless Network Setup Wizard to easily and
securely set up the DSM-G600 on a wireless network. You will need to have a USB flash drive
available to complete the WCN wireless setup on the DSM-G600.
If you do not have Windows XP (SP2) or do not wish to use WCN to setup your wireless settings
,
skip to page 16 to connect to a wireless network.
Windows
®
Connect Now (WCN)
Windows Connect Now
Click Start > Accessories >
Communications > Wireless Network
Setup Wizard.
Click
Next.
If you have already used WCN to configure other
wireless devices on your network and would like
to use the same settings on your DSM-G600,
click Add new computers or devices to the
‘Wireless Network’ network and skip to page
15 to continue.
To create new wireless settings, click Setup a new
wireless network
.
Click Next.
