20
DSM-G600 User’s Manual
D-Link Systems, Inc.
Mapping a Drive (continued)
Mapping a Drive
Double-click the My Computer
icon on your desktop.
Once connected, all shared folders will appear in My Computer.
Double-click on the mapped
drive to access the files and
folders.
