D-Link DSM-G600 [63/74] Checking the ip address in windows xp
![D-Link DSM-G600 [63/74] Checking the ip address in windows xp](/views2/1045701/page63/bg3f.png)
63
DSM-G600 User’s Manual
D-Link Systems, Inc.
Networking Basics
This window will appear:
Click the Support tab. This screen will list your IP address, subnet mask, and the
default gateway.
Click Close.
The wireless adapter-equipped computers in your network must be in the same IP
Address range (see Getting Started in this manual for a definition of IP Address Range).
To check the IP Address of the adapter, please do the following:
Right-click on the Local Area Connection icon in the task bar.
Click on Status.
Checking the IP Address in Windows XP
