18
DSM-G600 User’s Manual
D-Link Systems, Inc.
Mapping a Drive
Mapping a Drive
You can use the D-Link Easy Search Utility to map drives to your computer.
Insert the DSM-G600 CD into your
CD-ROM drive.
Click Launch D-Link
Easy Search Utility
.
Highlight an available DSM-G600
.
Available shares will be displayed
under Link Info. Highlight the share
you want to map.
Select an available drive letter from the
drop-down menu and click Connect.
Click
Disconnect to remove the selected mapped drive.
Once connected, your mapped drive(s) will appear in My Computer. From your
desktop, double-click the My Computer icon and then double-click your mapped
drive to access the files and folders.
