27
DSM-G600 User’s Manual
D-Link Systems, Inc.
Using the Setup Wizard (continued)
You have completed the basic configuration using the setup wizard!
Click Restart.
If your wireless network is using WPA-PSK
security, click WPA-PSK and enter the
encryption settings.
If your wireless network is using WEP
security, click WEP and enter the
encryption settings.
Click Next.
Click Next.
Using the Configuration Utility
