23
DSM-G600 User’s Manual
D-Link Systems, Inc.
Using the Setup Wizard
Using the Configuration Utility
The Wizard will guide you through five
steps:
- Password
- Time Zone
- LAN Connection Settings
- Additional Settings
- Wireless Connection Settings
Create a new password for your
DSM-G600.
Select your Time
Zone from the
drop-down menu.
Click Next
Click Next
Click Next
