68
DSM-G600 User’s Manual
D-Link Systems, Inc.
Technical Specifications
Technical Specifications
Standards
• IEEE 802.11
• IEEE 802.11b
• IEEE 802.11g
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab
Device Management
• Web-Based – Internet Explorer v6 or later; Netscape Navigator v7 or later; or other Java-enabled
browsers.
Data Rates
1
Data rates with automatic fallback:
• 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 11Mbps, 9Mbps, 6Mbps, 5.5Mbps, 2Mbps,
1Mbps
Security
• WEP (64 and 128-bit)
• WPA-PSK (TKIP and AES)
• WPA (TKIP and AES) with RADIUS server
Wireless Frequency Range
• 2.4GHz to 2.4835GHz
Wireless Operating Range
2
• Indoors: Up to 328 feet (100 meters)
• Outdoors: Up to 1,312 feet (400 meters)
1 Maximum wireless signal rate based on IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions
and environmental factors, including volume of network traffic, building materials and construction, and network overhead lower
actual data throughput rate.
2 Environmental factors may adversely affect wireless signal range.
Ports
• 1 10/100/1000 Gigabit Ethernet Port
• 2 USB 2.0 Ports
• Power
Power
• Output: 12V, 3A
• Max Power 36W, 100-110V
Modulation Technology
• Orthogonal Frequency Division Multiplexing (OFDM)
• Complementary Code Keying (CCK)
Weight
• 1.7 lbs.
