14
DSM-G600 User’s Manual
D-Link Systems, Inc.
If you want to manually assign a network key
select Manually assign a network key.
This screen appears if you choose to set the
WEP key manually. Enter the desired encryption
key in the space provided and then enter the key
again to confirm.
Enter the network name (SSID).
If you want Windows to assign a random
network key (encryption key), select
Automatically assign a network key.
To use WPA-PSK, select Use WPA
Encryption instead of WEP
.
Click Next.
Windows
®
Connect Now (Continued)
This screen appears if you choose to set the
WPA key manually. Enter the desired encryption
key in the space provided and then enter the key
again to confirm.
Click Next.
Click Next.
Windows Connect Now
